MOUNT
P/N 12302102
P/N J17068-1
NSN 5342 01 117 8027
MFG US ARMY

NEW GOV SURPLUS
SUPPLIER CAGE CODE 03EF7

ITEM NAME: MOUNT,RESILIENT,WEA
DEFINITION: An item made of material having elastic properties. It may have rigid
mounting facilities such as a flange(s), sleeve(s), stud(s) or the
like. It is designed to isolate or dampen shock and/or vibration of a
continuous or intermittent origin and serve as a support for a weapon
system component to be isolated. Excludes MOUNT, RESILIENT, UTILITY;
SPRING (as modified); BUMPER, NONMETALLIC; BUMPER, RUBBER; BUSHING,
NONMETALLIC; hydraulic and pneumatic shock absorbers, dash-pots,
grommets, and shock pads.

CHARACTERISTIC VALUE
FLANGE THICKNESS 0.335 INCHES NOMINAL
THREAD SIZE 0.500-20 ALL THREADED PORTIONS
DISTANCE BETWEEN MOUNTING 10.380 INCHES NOMINAL
HOLE CENTERS
FLANGE LENGTH 12.070 INCHES NOMINAL
FLANGE WIDTH 7.250 INCHES NOMINAL
FLANGE MOUNTING HOLE 0.530 INCHES NOMINAL
DIAMETER
SPECIAL FEATURES USED ON ARMED BATTLE TANK; MODEL NO. M1E1,NSN
2350-01-087-1095: AND IMPROVED TANK; MODEL NO.
M11A,NSN 2350-01136-8738
HEIGHT 1.915 INCHES NOMINAL
MFR SOURCE CONTROLLING 12302102
REFERENCE
SPEC/STD CONTROLLING DATA 19207
MANUFACTURERS CODE
STYLE DESIGNATOR RECTANGULAR FOUR INTERNALLY THREADED FLANGES
TWO-HOLE FLANGE
