PIPE CAP
P/N WWP460
NSN 4730 00 231 2402

ITEM NAME:   CAP,PIPE
DEFINITION:  A pipe fitting primarily designed for permanent installation during
             piping system operation to fit over or butt against a pipe or pipe
             fitting for sealing. Excludes FLANGE, PIPE, BLIND.


CHARACTERISTIC                          VALUE
THREAD DIRECTION                        RIGHT-HAND INTERNAL
NOMINAL PIPE SIZE FOR WHICH             1.500 INCHES
DESIGNED
CONNECTION STYLE                        PLAIN (OPTIONAL END)
MAXIMUM OPERATING PRESSURE              125.0 POUNDS PER SQUARE INCH
NOMINAL THREAD SIZE                     1.500 INCHES INTERNAL
MATERIAL                                COPPER ALLOY 838 OR COPPER ALLOY OVERALL
MATERIAL DOCUMENT AND                   QQ-C-390,CP 3 FED SPEC SINGLE MATERIAL RESPONSE OR
CLASSIFICATION                          ASTM B61 ASSN STD SINGLE MATERIAL RESPONSE OVERALL
MEDIA FOR WHICH DESIGNED                STEAM
DEFINITIVE GOVERNMENT                   MS14310-8A
SPEC/STD REFERENCE
MANUFACTURERS CODE                      81348
NON-DEFINITIVE GOVERNMENT               WWP460
SPEC/STD REFERENCE
SPEC/STD CONTROLLING DATA               96906
MANUFACTURERS CODE
STYLE DESIGNATOR                        CAP
THREAD SERIES DESIGNATOR                NPTF INTERNAL
SPECIFICATION/STANDARD DATA             81348-WW-P-460 GOVERNMENT SPECIFICATION AND
                                        96906-MS14310 GOVERNMENT STANDARD
NONDEFINITIVE SPEC/STD DATA             A CLASS AND PRESSURE RATING 1



MFG  FEDERAL SPECIFICATIONS
NEW GOV SURPLUS
SUPPLIER CAGE CODE 03EF7
