GEAR SPUR
PN 537AS580
NSN 3020-01-029-9508
MFG NAVAL AIR WARFARE

NEW GOV SURPLUS
SUPPLIER CAGE CODE 03EF7

ITEM NAME:   GEAR,SPUR
DEFINITION:  A gear, cylindrical in form, with straight teeth on the outer surface
             parallel to the axis of the gear. See also GEAR, ANTIBACKLASH, SPUR.
             For bulk material, see ROD, PINION.


CHARACTERISTIC                          VALUE
BODY STYLE                              WEBBED, OFFSET, SOLID
PITCH DIAMETER                          3.5000 INCHES NOMINAL
TEETH QUANTITY                          42
BORE STYLE                              W/COUNTERBORE BOTH ENDS
III HARDNESS RATING                     33.0 ROCKWELL C MINIMUM AND 38.0 ROCKWELL C
                                        MAXIMUM OVERALL
NOMINAL OUTSIDE DIAMETER                3.657 INCHES
TOOTH FORM                              STANDARD
PRESSURE ANGLE                          20.0000 DEGREES
NOMINAL DISTANCE BETWEEN                1.890 INCHES FIRST END 0.120 INCHES SECOND END
BODY FACE AND PROTRUDING
HUB END
FACE NOMINAL WIDTH                      0.360 INCHES
BORE NOMINAL DIAMETER                   0.300 INCHES BOTH ENDS 0.500 INCHES SECOND END
COUNTERBORE NOMINAL DEPTH               1.390 INCHES FIRST END 0.370 INCHES SECOND END
                                        0.500 INCHES SECOND COUNTERBORE, FIRST END
COUNTERBORE NOMINAL                     1.692 INCHES FIRST END 0.375 INCHES SECOND END
DIAMETER                                2.130 INCHES SECOND COUNTERBORE, FIRST END
HUB STYLE DESIGNATOR                    2 STEPS FIRST END PLAIN SECOND END
END NOMINAL LENGTH                      0.760 INCHES FIRST END
END NOMINAL DIAMETER                    2.130 INCHES FIRST END
FIRST STEP NOMINAL LENGTH               0.920 INCHES FIRST END
FIRST STEP NOMINAL DIAMETER             2.500 INCHES FIRST END
SECOND STEP NOMINAL LENGTH              0.210 INCHES FIRST END
SECOND STEP NOMINAL                     2.700 INCHES FIRST END
DIAMETER
SPECIAL FEATURES                        WEBBED INSIDE BORE; FIRST END SLOTTED AND GROOVED
III MATERIAL                            STEEL COMP 4140 OVERALL
MATERIAL DOCUMENT AND                   QQ-S-624 FED SPEC SINGLE MATERIAL RESPONSE OVERALL
CLASSIFICATION
STYLE DESIGNATOR                        PROTRUDING HUBS
