CONNECTOR RECEPTACLE P/N 370-0101-030 P/N HDAC62A03

NSN Number : 5935 01 465 1494 Category :

$2,000.00

Part Number: 5935 01 465 1494

Manufacturer: ROCKWELL COLLINS

Manufacturer's Product Number: 5935 01 465 1494

Condition: New

32 in stock

CONNECTOR RECEPTACLE
P/N 370-0101-030
P/N HDAC62A03
P/N NH-370-0101-030
P/N 370-0101
NSN 5935-01-465-1494

MFG ROCKWELL COLLINS
NEW GOV SURPLUS, SUPPLIER CAGE CODE 03EF7
FREE SHIPPING

ITEM NAME CONNECTOR,RECEPTACL
DEFINITION An electrical fitting with electrical contacts constructed to be
affixed to the end of a cable, conduit, coaxial line, cord, wire
(includes printed/etched), PRINTED WIRING BOARD, or the like for
convenience in joining with another electrical connector(s) or PRINTED
WIRING BOARD. It is designed to be mounted on a bulkhead, chassis,
panel, wall, PRINTED WIRING BOARD, or the like. Excludes LAMPHOLDER;
JACK, TELEPHONE; JACK, TIP; INSERT ELECTRICAL CONNECTOR; INSERT
MODULE, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified) and SOCKET,
PLUG-IN ELECTRONIC COMPONENTS. See also WIRING HARNESS (as modified)
and CABLE ASSEMBLY (as modified). For items with termination wires of
more than four inches in length, see LEAD ASSEMBLY, ELECTRICAL. For
items without inserts, see SHELL, ELECTRICAL CONNECTOR.

CHARACTERISTIC VALUE
III BODY STYLE STRAIGHT SHAPE
OVERALL LENGTH 2.750 INCHES NOMINAL
OVERALL HEIGHT 0.850 INCHES NOMINAL
OVERALL WIDTH 0.650 INCHES NOMINAL
DISTANCE BETWEEN MOUNTING 2.500 INCHES NOMINAL
FACILITY CENTERS
MATING END QUANTITY 2
CONTACT POSITION 2 ROWS OF CONTACTS NON-INSERTED BOARD SINGLE
ARRANGEMENT STYLE MATING END
CONNECTOR LOCKING METHOD JACKSCREW
III END ITEM IDENTIFICATION VALVE ASSEMBLY, ENVIRONMENTAL CONTROL
TERMINAL LOCATION FRONT SINGLE MATING END SINGLE CONTACT GROUPING
CONTACT MATERIAL COPPER ALLOY SINGLE MATING END SINGLE CONTACT
GROUPING
CONTACT SURFACE TREATMENT GOLD SINGLE MATING END SINGLE CONTACT GROUPING
TERMINAL TYPE PRESS-FIT PIN SINGLE MATING END SINGLE CONTACT
GROUPING
SHELL MATERIAL PLASTIC POLYESTER
SHELL SURFACE TREATMENT CADMIUM
INCLUDED CONTACT QUANTITY 62 SINGLE MATING END SINGLE CONTACT GROUPING
INCLUDED CONTACT TYPE ROUND PIN SINGLE MATING END SINGLE CONTACT
GROUPING
SPECIAL FEATURES SHELL FINISH CADMIUM PLATE IAW QQ-P-416, TYPE II,
CLASS 2; A PRELIMINARY PLATING OF ANOTHER METAL IS
PERMISSIBLE, FINISH SHALL BE ELECTRICALLY
CONDUCTIVE AND SHALL BE YELLOW TO GOLD IN COLOR;
CONTACTS GOLD PLATE, .000050 INCH MINIMUM
THICKNESS IAW MIL-G-45204 OVER NICKEL UNDERPLATE
.000050 THICKNESS; CONTACT SIZE 22; SHELL SIZE 4;
OPERATING TEMPERATURE -55 DEGREES C TO 70 DEGREES
C
NUCLEAR HARDNESS CRITICAL HARDENED
FEATURE
III PRECIOUS MATERIAL AND CONTACT PLATING GOLD
LOCATION
III PRECIOUS MATERIAL GOLD
